Kia Sportage: Climate Control Air Filter: Repair procedures
Third generation SL (2010–2016) / Kia Sportage SL Service & Repair Manual / Heating,Ventilation, Air Conditioning / Blower / Climate Control Air Filter: Repair procedures
| Replacement |
| 1. |
Disconnect the damper (B) and glove box lift (C) from the glove box (A).
|
| 2. |
Remove the filter cover with pushing the knob.
|
| 3. |
Replace the air filter (B), install it after making sure of the direction of air filter.
|
| 4. |
Installation is the reverse order of removal. |
