Type A
Type B
Type C
1. Model Name
2. Maximum allowable load
3. When using the jack, set your parking brake.
4. When using the jack, stop the engine.
5. Do not get under a vehicle that is supported by a jack.
6. The designated locations under the frame
7. When supporting the vehicle, the base plate of jack must be vertical under the
lifting point.
8. Shift into Reverse gear on vehicles with manual transmission or move the shift
lever to the P position on vehicles with automatic transmission.
9. The jack should be used on firm level ground.
10. Jack manufacturer
11. Production date
12. Representative company and address
Instrument panel overview
1. Lighting controls / Turn signals
2. Steering wheel audio controls
3. Instrument cluster
4. Horn
5. Driver’s front air bag
6. Cruise controls
7. Wiper/Washer switch
8. ENGINE START/STOP but ...
Engine compartment
GDI engine
T-GDI engine
1. Engine coolant reservoir
2. Engine oil filler cap
3. Brake/clutch* fluid reservoir
4. Positive battery terminal
5. Negative battery terminal
6. Fuse box
7. Air c ...
